What is PTW in Industries and Types of Safety Work Permit

Types of safety work permit—In chemical Industries, different types of breakdowns, maintenance of equipment, installation of new equipment, and many other things happen daily in the running plant.

Every work being conducted in industries involves risk, and we have learned in the hierarchy of risk control that we can only reduce the risk and can’t eliminate it completely. Work permits come under the Administrative tool in the safety hierarchy.

If you survey the accident data, you will find various accidents can be avoided if the work permit system is followed. Whether it is a chemical industry, polymer industry, construction site, or any workplace, a work permit plays a vital role in creating a safe working environment and helping to reduce accidents at the workplace.

Suppose you are a chemical engineer or working in a production/manufacturing department. In that case, it’s important for you to learn about a safety work permit and which work permit to issue for the particular job. The maintenance department person, i.e. Electrical, mechanical, and instrument department person, should also know about the permit system and need to know which permit should they want for the particular work.

Today in this article, we are going to learn what is a safety work permit, what is the purpose of the work permit system, the application of permits, and the types of permits to work. This is just an introduction article, In-depth knowledge is required in which all the aspects should be covered. Now let us dive into the permit guide.

What is Permit to Work in Safety (PTW)

PTW stands for Permit-to-work, can be defined as written and documented, which authorizes persons to perform specific work at a specific place and for a definite time frame. A safety permit helps to reduce the potential hazard to carry out job/work by making the production and maintenance department aware of the work that needs to be carried out.

Permit to work can be considered as written communication between the production and maintenance department that all the potential hazards are identified and steps related to reducing the risk have been taken and written permission to work. (Reference – Tata Power)

Why would you need a Permit to Work system?

The main purpose of a Permit to work is to make the work safer for the maintenance department and provide them with written permission to work. It plays an important role in risk assessment and prevents hazards involved in the job. The main purpose of a safety permit is to control high-risk activities and safeguard the working person from hazards and risks.

Types of Safety Work Permit System

1. General Work Permit
2. Hot Work Permit
3. Height Work Permit
4. Confined space permit
5. Excavation Work Permit
6. Electrical Work Permit
7. Process interlock bypass permit
8. Line breaking work permit
9. Special Hazard Work Permit

1. General Work Permit | Cold work permit

General work permits are also known as cold work permits. The basic definition of a General work permit is a job or work that doesn’t involve work that can be included in Hot work; height work and confined space are considered as cold work. This generally includes work in which no heat or spark will be generated or work at height.

Example of Cold work

• Valve changing work
• Bolt changing of pipe
• Material shifting work
• Painting work
• Gasket changing work

2. Hot Work Permit

If the work that needs to be conducted will generate heat or spark is considered as hot work, and for conducting the work, a hot work permit is issued. Cutting, welding, soldering, and brazing operations are considered hot work. In industries, various solvents and flammable chemicals and gases are used for production and other purposes.

While conducting hot work, there is a possibility that heat generated from the work can cause fire to the chemical present in the area and cause fire/explosion in the area. Hence, a hot work permit is issued, which ensures that no flammable material is present in the area and that another possibility of fire is eliminated.

Example of Hot work

• Welding
• Pipe cutting and fabrication work
• Grinding
• Bolt cutting work
• Forging

The hot work permit is a huge topic; hence it is being covered in an individual article that includes hot work procedures and hazards.

3. Height Work Permit

If work needs to be done at a certain height from the ground level and if a person falls while working and can be injured, it is considered height work. For conducting that work, a height work permit needs to be issued. Generally, work having a height of more than 1.8 meters comes under height work.

There is always risk involved in height work, as the men working at height can get injured and even fatal if they fall from a certain position. Hence, a Height work permit is issued that ensures that the men can work safely and have a full-body harness and safety belt.

4. Confined Space Permit

A confined space permit is also known as vessel entry. Industries and some workplaces have some equipment and areas that fall under Confined space are which are not meant for work persons but have a provision for personnel entry to perform a certain task. Confined space entry is considered to be the most critical one; hence, extra care needs to be taken while issuing a confined space permit. There are several checkpoints available prior to issuing a vessel entry permit, and here are some of them listed

• Ventilation inside the equipment/vessel
• Oxygen content
• Proper lighting
• Presence of any chemical or gas
• Deenergized of any equipment present inside the equipment like the agitator in the reactor
• Applied blind to any input and output stream to the vessel

Example of Confined space work

• Spark test in the reactor
• Agitator maintenance and inspection
• Rubber lining inside the tank
• Cleaning of reactor, tank, and tower

The confined space entry permit is discussed in detail including hazards associated with vessel entry permit and explained with examples in OSHA Confined Space Entry permit.

5. Energized Electrical Work Permit | Electrical Work Permit

Work near high-tension lines, low-tension lines, and live electrical components should be de-energized to avoid electric shock accidents. If maintenance work needs to be done on process equipment like a pump, bucket elevator, belt conveyor, etc., de-energized to prevent accidents that can be caused by the machine’s running.

While taking vessel entry into the reactor having agitator inside, de-energized of the agitator is also done to avoid an accident by rotation of the agitator while the person working inside the reactor. If there is a requirement of a person to get inside equipment, then the Lockout Tagout procedure is to be followed in which also, and energy isolation of the machine is also performed.

6. Excavation work permit

Excavation work means digging a hole, making a pit, or removing soil. This permit is usually required at construction sites and even in industries for new project work. An excavation work permit is required if certain work needs to be performed below the ground level at a depth of more than 1.5m. If the depth is less than 1.5 meters, then barricading is mandatory to safeguard a person from slipping into the pit.

Excavation work example

• Cutting or road
• Digging for foundation
• underground pipe installation
• Pit construction

7. Process interlock bypass request form

In an automation plant, DCS and PLC systems are used to operate plant operations, and plant parameters are used to control them using panels. In automated plants, plant tripping is provided as a part of process safety and for those interlocks are defined. These interlocks play an important role as they provide an extra layer of safety in process plants.

In a running plant, if maintenance is to be performed on any process equipment on which the interlock is defined, an interlock bypass is required as it can trip the whole plant. In that case, the process department issues process interlock bypass request forms to the instrument department to temporarily bypass the interlock.

8. Special Hazard Work Permit

Special hazard work permits and industry and workplace-specific, designed based on the hazard present in that particular organization. Link Nuclear power stations where the potential hazard is nuclear waste and radiation. In those industries, special hazard work permits are issues which are designed to safeguard people from those hazards

FAQ (Types of Safe Work Permit)

Wrapping Up

This is the detailed information on Permit to Work including the types of safety work permit in industries. If you have any doubts regarding the permit system in chemical industries then feel free to use the comment section. Don’t forget to share types of permits used in your industries and if any other types are being used in your organization then do share with us and let us know the purpose and application in detail.
